Overview

FMB003 is an ultra-small plug-and-play device built for OBD applications. Its key feature is reading OEM parameters (PIDs) directly from the vehicle's OBD port, giving access to real odometer and real fuel level data — with a supported-vehicle list so you know in advance what data a specific vehicle exposes. It suits fleet management of light commercial vehicles, driver log-books, insurance telematics (UBI), and car rental & leasing.

Key Features

Reads OEM parameters (PIDs) via the OBDII port for real odometer and fuel level data
Supported-vehicle and data list removes the guesswork on what each vehicle exposes
Plug-and-play installation directly into the OBDII socket
Bluetooth 4.0 + LE for external sensors, beacons and hands-free headsets
Firmware and configuration updates via Bluetooth
Crash detection based on accelerometer data
Towing and unplug detection
Auto and manual geofencing with trip detection
Green driving, over-speeding and excessive idling detection
GSM jamming detection
GNSS fuel counter alongside OBDII/OEM fuel level readings
Multiple sleep modes: GPS Sleep, Online Deep Sleep, Deep Sleep, Ultra Deep Sleep
OTA firmware & configuration updates (FOTA, USB/Bluetooth configurator, FMBT app)
Nano-SIM

Applications

Fleet management
Driver log-book
Insurance telematics (UBI)
Car rental & leasing
Connected car

Specifications

GNSS

Spec	Value
Receiver	33 channel
Tracking sensitivity	-165 dBm
Position accuracy	< 2.5 CEP
Velocity accuracy	< 0.1 m/s (within ±15% error)
Hot start	< 1 s
Warm start	< 25 s
Cold start	< 35 s
Systems	GPS, GLONASS, Galileo, BeiDou, SBAS, QZSS, DGPS, AGPS

GSM / Connectivity

Spec	Value
Bands	Quad-band 850/900/1800/1900 MHz
Data transfer	GPRS Multi-Slot Class 12 (up to 240 kbps)
Data support	SMS (text/data)
SIM	Nano-SIM

Bluetooth

Spec	Value
Specification	4.0 + LE
Supported peripherals	Temperature & humidity sensor, headset, barcode scanner, universal BLE sensors

OBD Interface

Spec	Value
Connection	OBDII socket (plug-and-play)
Data	HS CAN, MS CAN, SW CAN, K-Line
Data reading	OEM fuel level, odometer, up to 32 onboard parameters
Supported protocols	ISO 9141-2, ISO 14230-4 KWP, ISO 15765-4 CAN (11/29-bit), ISO 14229 (UDS), J2819 (VW TP2.0)
