Overview

FMC650 is a leading GNSS/LTE/GSM/BLE terminal built for advanced fleet applications. It combines 4G LTE Cat 1 connectivity with 2G fallback, dual-channel L1+L5 GNSS positioning, and an extensive interface set — including RS232, RS485, dual CAN (J1939/J1708) and K-Line — for reading tachograph and heavy-vehicle data. Dual-SIM support and a Bluetooth 5.0 LE radio round out a device designed for trucks, buses and other professional fleets.

Key Features

4G LTE Cat 1 connectivity (10/5 Mbps) with automatic 2G fallback
Dual-channel L1 + L5 GNSS receiver for improved accuracy in dense urban areas
Dual-SIM support for network redundancy and roaming flexibility
Bluetooth 5.0 LE for external sensors and peripherals
Two RS232 ports plus one RS485 port for third-party device integration
Two CAN interfaces (J1939, J1708) with switchable termination
K-Line interface for reading tachograph data
Real fuel consumption and odometer calculation from CAN/tachograph data
Crash detection, towing detection and excessive idling alerts
Eco/green driving monitoring
Auto and manual geofencing with trip start/end detection
GSM jamming detection
Offline tracking mode when out of network coverage
OTA firmware and configuration updates (FOTA)
External high-gain GNSS antenna support

Applications

Heavy duty transport
Trailer tracking
Refrigerated transport
International logistics
Public transport
Rental & leasing fleets

Specifications

GNSS

Spec	Value
Receiver	Dual-channel L1 + L5 (75 channels L1 / 60 channels L5)
Position accuracy	< 2.5 m CEP
Systems	GPS, GLONASS, Galileo, BeiDou, QZSS
Antenna	External high-gain GNSS antenna support

Cellular / Connectivity

Spec	Value
Technology	4G (LTE) Cat 1 (10 Mbps / 5 Mbps), with 2G (GSM) fallback
LTE bands (FDD)	1, 3, 7, 8, 20, 28
SIM	Dual-SIM

Bluetooth

Spec	Value
Specification	5.0 LE
Supported peripherals	Temperature & humidity sensor, universal BLE sensors

Interface & Hardware

Spec	Value
Digital inputs	4
Digital outputs	4
Analog inputs	4
1-Wire	1
RS232	2
RS485	1
CAN	2× J1939, 1× J1708 (switchable terminals)
K-Line	1 (tachograph data)
USB	1× Mini-USB 2.0
